Single Screen Ruggedized Desktop Computer

▶ CPU:Intel® Core™ 10th/11th generation I3/I5/I7 (125W) processor
▶ Memory:2*DDR4 DIMM memory slot, supports 64G
▶ Display:1*VGA port, 2*HDMI port
▶ Hard disk:4*SATAⅢ, 1*M.2 M key2242/2280 (SATA4 interface and M.2 interface share signal)
▶ Network:1*Intel®i219-LM Gigabit network port, 1*Intel®i225-V 10/100/1000/2500 Mbps
▶ USB:4*USB 3.2 Gen 1. 2*USB2.0, 2*USB2.0 (internal IO) 1*USB2.0 (internal TYPE-A)
▶ Display screen:17.3 inches, 1920*1080 resolution, LCD screen
▶ Input device：82-key keyboard, capacitive touch panel
▶ Dimensions:430*340*200mm,weight about 9.5Kg
▶ Operating system：Windows 10/11, Centos, Ubuntu

▶ Model: SIN-D1771-JH420

▶ CPU：supports Intel®Core™ 10th generation I3/I5/I7 and Xeon W series processors
▶ Memory：4*DDR4 UDIMM memory slots,supports 128G
▶ Display port:1*HDM interface, 1*DP interface, 1*VGA interface
▶ Display:Size: 17.3"TFT LCD, resolution: 1920×1080, brightness: 300cd/m²
▶ Hard disk:4*SATAⅢ slots
▶ Network:3*Intel®I210-AT Gigabit network port, 1*Intel®I219LM Gigabit network port
▶ USB:13*USB ports (6*USB3.2 Gen 2 (IO side), 2*USB3.2 Gen 1 (internal IO), 2*USB2.0 (IO side), 2*USB2.0 (internal IO), 1*USB2.0 (internal TYPE-A)
▶ Dimensions:427x340x186mm,weight about 10kg
▶ System support:Windows 10, Windows server 2016, Centos, Ubuntu

▶ Model: SIN-2772-WW480MA

▶ CPU:supports Intel® Core™ 6/7 generation 13/15/17 processors
▶ Memory:4*288pin DDR4 memory slots, supports 64G memory
▶ Display:1*VGA port
▶ Hard disk:6*SATAIII ports, chassis supports 1*3.5inch hard disk + 2*2.5inch hard disk
▶ Network:2*Intel® i210 Gigabit network port
▶ USB:9*USB ports (5*USB3.0 ports, 4*USB2.0 ports)
▶ Display screen:Size: 17.3"TFT LCD, resolution: 1920×1080, brightness: 300cd/m²
▶ Size:427x340x186mm,weight about 10kg
▶ Operating system:Windows7, Windows 10, Windows server 2016, Linux

▶ Model: SIN-2772-SX11SSL

▶ CPU: supports Intel® 10/11 generation processors
▶ Memory: 2*DDR4 SO-DIMM memory slot,supports 64G
▶ Hard disk: 4*SATAIII ports, 1*M.2 M-key 2242/2280 PCIex4 slot supports NVMe SSD
▶ Display:15.6-inch LED screen, 1920*1080 resolution
▶ USB: 6*USB3.2 ports, 3*USB2.0 ports (optional)
▶ COM: 2*RS232/422/485, 4*RS232 (optional)
▶ Dimensions and weight: 380×290×77.6 (mm), 5KG
▶ System support: Windows 10, Ubuntu, Centos

▶ Model: SIN-1415CU-Q470

▶ Display：15.6-inch + 13.3-inch high-brightness screen,resolution 1920*1080, 1000nit
▶ CPU：12th generation intelligent Intel JCore i5-1235U
▶ Hard disk：480G solid-state drive
▶ Memory：DDR4 16GB
▶ Size:390*280*67mm,weight about 6.8kg
▶ Protection level:Protection level IP54
▶ Wireless communication:WiFi & Bluetooth, 5G public network, support GPS Beidou + 5G router
▶ Battery:Typical battery life 4 hours

▶ Model: SIN-S1425CU-1235U

▶ CPU:supports Intel 12/13/14th generation Core/Pentium/Celeron desktop processors
▶ Memory:2*DDR4 3200 MHz memory slots, , supports up to 64G
▶ Display:1*17.3inch display, resolution 1920*1080, brightness 500cd/m²
▶ Display port:1*VGA , 1*HDMI(for connecting to the display), 1*DVI
▶ Storage:3*SATA3.0, 1*M.2 M-key 2242/2280 (PCIex2/SATA)
▶ USB:8*USB [4*USB3.0, 4*USB2.0 (2*internal lead)], and 1*USB2.0
▶ Dimensions:455*339*180mm weight about 11kg
▶ Support System:Windows10/11, Linux

▶ Model:SIN-1417AD-H610

▶ Display：1*17.3-inch display, resolution 1920*1080, brightness 500cd/m², with anti-glare film
▶ CPU:Supports Core 6/7/8/9/10/11/12/13/14 generation processors
▶ Memory:2*DDR4 memory slots,32G/128G
▶ Display:1*VGA port,1*HDMI port (used for display),1*DVI
▶ Serial port:6*COM(2*RS232/485 internal lead)
▶ Dimensions and weight：455*350*211.2mm,weight about 14.5KG
▶ Supported system:Windows 7/8/10, Server 2008/2012, Iinux

▶ Model: SIN-1417ZD-BH31CMA/BH470MA/BQ670MA1

▶ Chipset:Intel®R680E chipset
▶ CPU: LGA1700 architecture, supports Intel® 12/13 generation processors
▶ Memory:Supports 64G DDR4 memory
▶ Hard Drive:3*SATAIII interface (supports RAID 0,1,5,10)
▶ Display:15.6-inch LED screen, 1920*1080 resolution
▶ Size:380x290x78(mm)
▶ Weight:5kg
▶ System support: Windows 10/11, Linux
▶ Application Areas：Outdoor exploration,Electric power work,Industrial manufacturing,Energy development

▶ Model: SIN-JU151-WR680MC

▶ Chipset:Intel®Q370 chipset
▶ CPU:supports Intel® Core™ 8/9 generation I3/I5/I7 processors
▶ Memory:Supports 128G DDR4 memory
▶ Hard Drive:4*SATAIII port
▶ Display:1*VGA port, 2*DP port
▶ Size:427x340x186mm
▶ Weight:10kg
▶ System support: Windows 10, Windows server 2016, Centos, Ubuntu
▶ Application Areas：Airport security check,Arrest scene control,Court trial evidence collection,

▶ Model: SIN-2772-ZQ370MAV2

The chassis is made of high-strength aluminum alloy, designed with crash-resistant pads around the perimeter, and the ports are covered with sealing plates to prevent dust and moisture.supports Supports 10th generation i3/i5/i7 processors，15.6" LED screen, 1920*1080 resolution,Brightness 300cd/m, viewing angle 178/170(H/V).support Q470E chipset，LGA1200 architecture, supports Intel 10th generation processors.2*DDR4 SO-DIMM memory slots, 2666MHz, supports 64G.Weight about 5kg, the lightest of portables.

Model:SIN-U157-JQ470MC

The chassis is made of high-strength aluminum alloy, and a sealing cover plate is used to prevent dust and moisture at the design port of the anti-collision pad around.15.6 inch wide screen 1920*1080 LED screen，Intel®H310 Chipset，Expandable to 64G memory 4 2.5 hard drives.

Model:SIN-U151-WH310

The Intel H110 chipset supports Intel® Core 7th generation i3/i5/i7 processors,Supports 32G DDR4 memory, 4 2.5-inch hard drive bays support RAID 0, 1, 5, 10, improving performance while protecting data.The chassis is made of high-strength aluminum alloy and is designed with anti-collision feet all around.The port adopts a sealed cover to prevent dust and moisture.15.6" wide screen 1920*1080 LED screen.

Model:SIN-U151-WH110

The Intel HM370 chipset supports Available with i7-7700HQ processor with quad-core and eight threads up to 3.8GHz，Aluminum-magnesium alloy shell, with high strength, small density, beautiful color, corrosion resistance, etc.1920 * 1080 resolution, 15.6-inch high-definition LCD screen, true restoration of the picture color, so that every second of the details are clear and smooth。IP65 protection level, can prevent most of the dust from entering, aluminum-magnesium alloy shell with high strength anti-shock effect.

Model:SIN-JP151-DH370MC

▶ CPU：Intel® Core™ 7th Generation i7-7700HQ Processor.
▶ Memory:Dual channel DDR4 2133MHz memory slot Up to 64G memory.
▶ Display:2xHDMI, 1xDP.
▶ Harddisk:1x2.5 inch hard drive,1T or 2TSSD hard drives can be added.
▶ Resolution: 1920*1080
▶ Size:380*290*50mm,Weight about 5kg.
▶ Application areas:Highway data collection,Emergency Command,Railway management.

Model:SIN-JP151-7700HQ

▶ Intel® Q370 Chipset supports Intel® Core8/9 generation l3/15/17 processors.
▶ 4*288pin DDR4 2666MHz UDIMM memory slots, support 64G memory.
▶ Display: 1 VGA port, 1 HDMI port, 2 DP ports.
▶ Resolution: 1920x1080, brightness: 300cd/m
▶ Hard drive: 6 SATA III ports, 1 M.2.M slot, 1 M.2.E slot.
▶ Size:427x340x186mm,weight about 10kg.
▶ Application areas:Court evidence collection,Airport security,Arrest site control,High-speed rail identity verification.

Model:SIN-2772-WQ370MA

▶ Intel® C612 Chipset support Intel® Xeon E5-2600/1600 series processors.
▶ Memory 8*ECC DDR4 RDIMM/LRDIMM memory slots, 2400 MHz, memory support 256GB RDIMM memory or 512GB LRDIMM memory
▶ Display:1 VGA port.
▶ Hard Drive: 10*SATAIII interfaces, 6 AHCI controllers support RAID 0.1.5.10.
▶ Size:430*450*177mm,weight about 10kg.
▶ Power supply:250W rated power (optional 300W/400W/500W power supply).
▶ Application areas:Machine Vision,Motion Control,Environmental monitoring,Data acquisition.

Model:SIN-2772-SX10SRL

▶ Intel® H110 Chipset support Intel® Core 6/7 generation l3/15/17 processors.
▶ 2*288pin DDR4 2400MHz UDIMM memory slots, support 32G memory.
▶ Display: 1 VGA port, 1 HDMI port, 1 DVI port .
▶ Hard disk:4 SATA III ports, 1 mSATA slot, support 1 3.5" hard disk and 2 2.5" hard disk.
▶ Size:427x340x186mm,weight about 10kg.
▶ 1920*1080 HD screen resolution.
▶ Application areas:Intelligent Device Manufacturing, Intelligent Transportation, Intelligent Healthcare.Image Data Acquisition. Environmental monitoring.

Model:SIN-2772-BH110MA
